High Quality Airbag Launching Ship Marine Rubber Airbags for Boat
Description
with decades of experience and a global client base, airbag launching technology has proven itself as a reliable choice worldwide. Its adaptability to various climates, water conditions, and shipyard layouts ensures consistent performance across different regions. The technology has been successfully used for launching yachts, cargo ships, and even military vessels.
Specifications
| Item | Description |
| Place of Origin | China |
| Brand Name | Hongruntong Marine |
| Model Number | HM-ALS028 |
| Material | Industrial-Grade Natural Rubber |
| Diameter | 0.5m-3.0m, or as Request |
| Length | 1.0m-28.0m, or as Request |
| Working Pressure | 0.05-0.25 mpa |
| Technics | High pressure, overall winding, explosion-proof |
| Use | ship launching and docking |
| Thickness | 5-13 ply |
| Standard | Conducted by ISO14409 and GB/T1590-2006 system. |
| Accessories | Q355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube |
| Packaging | Inner-Plastic Bag; Outer-Standard Wooden Pallets. |
| Keywords | Airbag Launching Ship |
| Certificates | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| MOQ | 1 |
| OEM | Welcome |
| Diameter | Working Pressure | Working Height | Bearing Capacity |
| KN/m | Ton/m |
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 |
| 0.4m | 131.95 | 13.46 |
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 |
| 0.5m | 131.95 | 13.46 |
| 0.4m | 150.80 | 15.39 |
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 |
| 0.7m | 125.66 | 12.82 |
| 0.6m | 141.37 | 14.43 |
| 0.5m | 157.08 | 16.03 |
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 |
| 0.9m | 127.33 | 12.98 |
| 0.8m | 141.37 | 14.43 |
| 0.7m | 155.51 | 15.87 |
| 0.6m | 169.65 | 17.31 |
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 |
| 1.0m | 125.66 | 12.82 |
| 0.9m | 138.23 | 14.11 |
| 0.8m | 150.80 | 15.39 |
| 0.7m | 163.36 | 16.67 |
| 0.6m | 175.93 | 17.95 |
| * Other size can be produced follow client's requirements. |
Features
Reliable Under Pressure
Performs well even under challenging conditions.
Weather Resistant
Operates effectively in various weather conditions.
Corrosion Resistant
Rubber materials resist corrosion from saltwater and chemicals.
Improved Production Efficiency
Faster and simpler process increases output.
Applications
● Livestock carrier launching
● Salvage vessel launching
● Container ship launching
● Naval destroyer launching
Advantages
Excellent Track Record
Successful projects completed for various shipyards globally.
Highly Adaptable Products
Airbags suitable for diverse weather and terrain conditions.
Technical Training Provided
Ensuring safe and efficient product use.
Flexible Payment Options
Supporting customers with convenient payment plans.
FAQ
1. Are there specific regulations for airbag launching?
It depends on local maritime guidelines, but we provide compliance advice.
2. Do you offer installation support?
Yes, we provide on-site and remote support.
3. What after sales services are available?
Maintenance, repairs, and technical consultations.
4. Is technical support available 24/7?
Yes, we provide round the clock assistance.
